moyes Gecko - Bolts and Pins List

GECKO OWNERS MANUAL
Version 3 36
BOLTS AND PINS LIST
Junction
Part No.
Qty.
Nut
Washers
Nose Plate & Leading Edge
Nose Plate/Leading Edge
AN4-25A
2
HALF
2 MED PL
Nose Plate/Keel/Front
AN4-30A
1
FULL
Nose Plate/Keel/Back
AN4-34A
1
HALF
Keel/Bailey Block Front
AN4-30A
1
FULL
Keel Rear
Keel/Bailey Block Back
AN3-23A
1
FULL
1 SS
Pullback Shackle
AN4-10A
1
HALF
Keel/Kingpost Bracket
AN4-31A
1
HALF
1 SS
Cross Bar & Leading Edge
Leading Edge/Cross Bar Plate
AN4-23A
4
HALF
4 SS
Cross Bar Leading Edge Hinge
AN5-12A
2
FULL
1 Pla Spc, 2 SS, 1 Pla Spc
Leading Edge/Mid-Section
MS20392-2C65
2
RING
Cross Bar Center
Cross Bar/Center (Right Hand) Rear
AN4-30A
1
FULL
2 PLASTIC
Cross Bar/Center (Right Hand) Front
AN4-30A
2
FULL
1 SS
Cross Bar/Center (Left Hand)
AN4-30A
1
FULL
2
Cross Bar/Center Ball
AN4-25A
1
HALF
1 SS
Cross Bar/Center/Hinge
AN4-12A
1
HALF
1 Pla Spc, 1 SS
Cross Bar/Top Wire Mount
RF347
2
RING
Cross Bar/Top Wire Mount
AN4-30A
2
HALF
2 SS, 2 SML PL
Strut & Leading Edge
Strut/Leading Edge
AN4-11A
2
HALF
Strut/Outboard Ball Joint
ROD END – PM5G
2 x 3.8mm SS Spacer
Strut/Outboard Cone/Tube 26mm
MS20392-2C33
2
RING
Apex
Zoom Uprights
MS20392-2C25
4
RING
Dingle Dangle Hangloop
AN5-34A
1
HALF
Dingle Dangle Keel
AN4-25A
1
HALF
1 SS
Dingle Dangle T Connector
AN4-12A
1
HALF
1 SS
Kingpost Bracket
Zoom A Frame
AN4-11A
1
HALF
Keel/Control Bar (A-Frame)
Upr End Pin Zoom
Top AN3
2
FULL
1 Spacer, 1 SS Plastic
King Post
AN5-31A
1
HALF
1 SS (5/16-5/8)
Top VG Pulley Keel Screw
PAN 8G 3/4
Misc. Not Pictured
Leading Edge/Sail Tension Retainer
MS20392-3C69
2
RING
Strut/Outboard Wire
MS20392-3C27
2
RING
Strut Outboard Wire/Leading Edge
MS24694S-131
2
HALF
1 SS, 2 PLST
Sail Screw Nose
CSK 10G 16 x ¾
4 WAS N11, Plastic Spacer
Sail Screw Keel
CSK 4G ¼
1 WAS N11
King Post
MS20392
3C15/3C11
Tip Wand Holder
MS24694-554
(AN3)
2
HALF
N11
