Installation of Magnetic Suction Paddle Mute Pad
(for detailed steering wheel settings and functions, please visit the ofcial website of MOZA Racing)
Place the steering wheel on a at surface with the surface facing down, use a hexagonal wrench to remove
the screw on one side of the shift paddle trigger rod, and then use a wrench to push the pin from the side of
the magnetic suction paddle (it is not necessary to push the pin out completely, only to separate the magnetic
suction paddle trigger rod and the pin), and then stick the mute pad on the convex position on the back of the
paddle trigger rod, as shown in the gure. Finally, return the latch, and replace the screw.
Frame material: Brushed aluminum alloy.
Panel material: Forged Carbon Fiber.
Rear shell material: Aluminum alloy.
Paddle material: 3mm thick forged carbon ber
Size: 13 inches (325mm).
Magnetic paddle: 2.
Double clutch paddles: 2.
Mechanical keyboard texture keys: 10. 20 Section
knob (can be pressed): 2. Universal rocker (can be d
pressed): 2. Racing horn: 1.
Product Spec
Installation of Paddle Approach Block
Use the hexagon wrench in the screw kit to remove the two screws on the shift paddle, add the heightening
block, and tighten it with the attached long screw. Using this gasket, the distance between the paddle and the
hand can be shortened by 8mm.
LED color: 7-color custom.
Intelligent telemetry: Supported.
Lights setting via Moza Pit House: Supported.
Steering Wheel Quick Release: D1 racing quick
release.
Power supply mode: Wireless.
Signal transmission mode: Wireless.
Induction mode of magnetic paddle: Photoelectric.
Magnetic suction paddle mode: Double Clutch /
Single Clutch / Switch.
