SYMBOL DESCRIPTION SETTING RANGE INITIAL VALUE
LEVEL 1
LEVEL 1LEVEL 1
LEVEL 1
rAmP
Setpoint Ramp
0.0 ~ 100.0 oC/minute
0
oPoF
Output Offset (Manual Reset)
0.0 ~ 100.0%
0
A1SP
Alarm 1 Setpoint Full Scale 10
timE
Alarm Delay Time (Only if
A1Fu is set to Timer)
0-9999 minutes
A2SP
Alarm 2 Setpoint Full Scale 10
LEVEL 2
LEVEL 2LEVEL 2
LEVEL 2
Pb
Proportional Band - Output 1 (0 for
on/off control)
0.0 ~ 100.0% of Input Scale
10
C Pb
Proportional Band - Output 2 (multiplier
of Pb) (Option - Second Output)
0.0 ~ 10.0 1
ti
Integral Time 0 ~ 3600 seconds 240
td
Derivative Time 0 ~ 3600 seconds 60
db
Deadband for Heat/Cool (multiplier of Pb)
(Option - Second Output)
-10.0 ~ 10.0 0
LEVEL 3
LEVEL 3LEVEL 3
LEVEL 3
rEmo
Remote Mode 0 ~ 1 (0 = Local ,1=Remote) 0
P-L
Parameter Lock 0 ~ 15 (see Table.3) 0
A1Fu
Alarm 1 Function 0 ~ 15 (see Table.3) 0
A2Fu
Alarm 2 Function 0 ~ 7 (see Table.3) 0
A1HY
Alarm 1 Hysterysis 0.0 ~ 25.5% span 0
A2HY
Alarm 2 Hysterysis 0.0 ~ 25.5% span 0
Act
Control Action 0 ~ 1 (0=Cooling-Direct ,1=Heating-Reverse) 1
unit
Display Units 0 ~ 2 (0=oF ,1=oC, 2=Engineering Units) 1
dP
Decimal Position 0 ~ 1 ( input TYPE 10 0~3) 0
Ct
Cycle Time - Output 1 0 ~ 100 seconds 15(relay) 1(volt pulse)
0(4-20Ma)
C Ct
Cycle Time - Output 2 0 ~ 100 seconds NOTE(Relay
output) Larger value = Longer relay life &
Slower control response
15(relay) 1(volt pulse)
0(4-20Ma)
HYSt
Hysteresis (Only for ON/OFF CONTROL
ie.Pb=0)
0.0 ~ 25.5% span 0.1
EroP
Error Protection 0 ~ 15 (see Table.3) 2
Addr
Communication Address 0 ~ 31 0
PYoF
Process Value Offset -100 ~ +100 0
tYPE
Sensor Input Type 0 ~ 10 (see Table.3) 1
LoLt
Low Limit Set value Full Scale 0
HiLt
High Limit Set value Full Scale 800
LEVEL 4
LEVEL 4LEVEL 4
LEVEL 4
LoCA
Low Point Calibration Full Scale (only for TYPE 10 Input)
HiCA
High Point Calibration Full Scale (only for TYPE 10 Input)
tunE
Autotuning Function 0 ~ 5 (see Table.3) 0
