Care Instructions
Technical Data:
Aperture: 400 x 400 mm
Corner radius: 25 mm
Size dome: 560 x 560 mm
Height over roof model 44P/ 4400P: 117 mm
model 46P/ 4600P: 92 mm
model 4751P/ 4753P: 96 mm
Free-air-fl ow: Please refer to model options
Outer frame material: Polypropylene
Dome material 4751P/4753P PC/ PMMA + SAN
Other models: Polypropylene
Product description
- Clear or opaque domes with free airfl ow
- Spring assisted mechanism, can be tipped in 4 directions, with locks
- concealed fi xing screws
- Inner frame with pleated fl ynet + blind (optional fl ynet only)
- ECE R43 Whole Vehicle Type Approved
(Please ask for further details.)
Technical Information
The roofl ight should only be washed by hand, using a sponge
with plenty of clean water to avoid scratching. Caustic detergents
and solvents may attack the plastic and make it brittle or disinte-
grate.
For easier cleaning of the dome it can be removed from the frame
by releasing the four screws holding the handle arms (models from
May 2010, Torx TK10 screws).
(See picture 12)
Make sure that only the original screws are used when replacing
the dome and that they enter the thread in the plastic correctly.
Do not over-tighten.
Never remove the screws holding the dome and the handles toge-
ther
(see picture 12). These are secured by a torque screwdriver
and should only be handled by an approved dealers.
To remove the inner frame for cleaning, with the fl ynet and blind
attached, follow the reverse of the fi tting instructions; removing
covers and screws.
Cleaning
