12
GB
6. Mount the fan head on the inner tube ⑮ element.
7. Tighten the screw located ⑬ on the controls cover ⑥.
USING THE FAN:
ATTENTION! Before switching on make sure the fan is placed on a flat, stable and dry surface!
1. Plug in the appliance.
2. Set the desired rotation speed using controls:
„0” - switched on, „1” - speed I, „2” – speed II, „3” – speed III.
3. To activate the rotating mechanism, press the rotating operation button ⑩ located on the
motor cover.
4. To change the angle of the propeller, and thus the angle of the air stream, simply tilt the fan
head by holding the controls cover with the second hand to prevent the fan from overturn-
ing.
5. In model MWP-17 the head height can also be adjusted by loosening the head height adjust-
ment nut ⑦, proper positioning of the head and tightening the nut.
CLEANING AND MAINTENANCE
1. Before cleaning the appliance, unplug it from the power outlet.
2. The motor cover, controls cover, stand and cross of the standing fan, base of the desktop fan,
may be cleaned with a damp cloth and a mild detergent.
3. The mesh guards may be occasionally wiped with a brush to remove dust from the holes.
4. After the propeller is unmounted, wipe it with a damp cloth with a detergent.
Technical data sheet
MPM AGD S.A.
MODEL: MWP-16 (MWP-17)
Description Symbol Value Unit
Maximum flow rate of the fan F 31,58 (53,45) m
3
/min
Fan power P 36,32 (41,95) W
Operating value SV 0,82 (1,27) (m
3
/min)/W
Power consumption in standby mode P
SB
0 W
Fan’s sound power level L
WA
54,3 (63,4) dB(A)
Maximum air speed c 2,437 (2,374) m/s
Seasonal electricity consumption Q 11,622 (13,424) kWh/a
Standards used for measuring the
operational values
PN-EN 50564:2011,
IEC 60879:1986 (corr.1992)
EN 60704-1:2010 + A11: 2012,
EN 60704-2-7:1998
To get additional information, contact MPM AGD S.A.
ul. Brzozowa 3
Milanówek 05-822, Polska
tel. (22) 380-52-00
BDO: 000027599
