Power Supply
AC 110/220V±10%
Frequency
50HZ±0.5
Relative Humidity
<85%
Environment Temperature
0℃～＋40℃
External Magnetic Field Strength
<400A/m
No Open Flames Are Allowed
Around
Structure And Composition
2.1 Structure
1.2 Working Environment And
Technical Parameters
Bright background light, you can
clearly see the various situations of
the fuel injector when it is working.
It has replaceable composite joints
suitable for a variety of vehicle
types.
Within the allowable adjustment
range, the test time, working
frequency, fuel injection times,
shortest switching period, etc. of
the fuel injector can be adjusted
arbitrarily.
Working Environment
Tank Capacity
2000 ml
Range Of Rotation
0-7500 r/min
PWM Pulse Width
0～20.0 ms step 0.1ms
Time
0～10 min
Cleaning Frequency
40 kHz
Cylinder Volume
180 ml
Injection Times
0～9900 times, step 100ms
System Pressure
0～0.6 Mpa
Ultrasonic Cleaning Power
70 W
Package Dimensions
340*295*360 mm
Technical Parameters
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑪
⑫
⑬
⑩
