Page 6
Overview - Display
mrcool.com
1. Digital Display
Displays the Temperature Setting when the air conditioner is operational.
Displays the Room Temperature when in FAN mode.
Displays the self-diagnostic codes.
Displays “ON” for three seconds when the Timer is ON and/or Fresh, Swing, Turbo or Silence feature is
activated.
Displays “OF” for three seconds when the Timer is switched OFF.
Displays “OF” for three seconds when the Fresh, Swing, Turbo or Silence feature is cancelled.
Displays “dF” when Defrosting operation is active.
Displays “cF” when Anti-Cold Air feature is active in HEAT mode (when air temp is low).
Displays “SC” during Self Clean operation (if feature is available).
Displays “FP” when Freeze Protection is active, operating under 46.4 °F (8 °C) (if feature is available).
2. Units of Measurement:
Displays “°C” for Celsius or “°F” for Fahrenheit. Default units are “°F” (Fahrenheit) and can be switched
by simultaneously press and hold both the up and down buttons on the remote control.
According to the operation mode (heat / cool, etc.), the Units of Measurement will display in different
colors;
· Under Cool or Dry mode, it always displays as cool colors.
· Under Heat mode, it always displays as a warm color.
3. Wireless Mode:
Displays when the wireless control feature is activated.
NOTE: A guide for using the infrared remote - “Remote Manual” - is included in this literature package.
4. Energy Saving Mode (optional):
Displays when Energy Saving Feature is active. Not available when the unit does not have Energy
Saving Mode
°
ECO
1
3
4
2
fig. 1.2
Display (on front panel of indoor unit) see g. 1.2
