Page 26
mrcool.com
Outdoor Unit Installation
If you will install the unit on a wall-mounted
bracket, do the following:
TO REDUCE VIBRATION OF WALL-
MOUNTED UNIT
Before installing a wall-mounted unit,
make sure that the wall is made of solid
brick, concrete, or of similarly strong
material. The wall must be able to
support at least four times the weight
of the unit.
1. Mark the position of bracket holes based on
dimensions in the Unit Mounting Dimensions chart.
2. Pre-drill the holes for the expansion bolts.
3. Clean dust and debris away from holes.
4. Place a washer and nut on the end of each
expansion bolt.
5. Thread expansion bolts through holes in mounting
brackets, put mounting brackets in position, and
hammer expansion bolts into the wall.
6. Check that the mounting brackets are level.
7. Carefully lift unit and place its mounting feet on
brackets.
8. Bolt the unit firmly to the brackets.
If allowed, you can install the wall-mounted
unit with rubber gaskets to reduce vibra-
tion and noise.
