MrCool Universal Series - Page 12

Page 11 mrcool.com
Unit Installation
inches (”) millimeters (mm)
Prohibited
1/2H < Hb ≤ H
Hb ≤ 1/2H
Hb > H
Hb H
Hb
H
B
≥ 15.75”
400mm
≥ 157.5”
4000mm
≥ 15.75”
400mm
≥ 23.62”
600mm
≥ 7.87”
200mm
≥ 7.87”
200mm
≥ 7.874”
2000mm
≥ 7.874”
2000mm
≥ 177.17”
4500mm
≥ 7.87”
200mm
≥ 7.87”
200mm
Fig. 2.3
For best performance of the outdoor unit, make sure its installation space conforms to the following
installation dimensions...
For installation of multiple condensers in rows refer to fig 2.3 below:
Installation Location
B ≥ 9.84” 250mm
B ≥ 11.81” 300mm
