The following combinations of modules installed in the front and in the rear are possible or
required:
Maximum Loads
NOTICE
Ensure that the maximum loads are not exceeded to guarantee a reliable operation.
Operating voltage may vary from 19.2 VDC to 32 VDC. The values specified below are for an
operating voltage of 24 VDC.
A MAT module covers 2 slots; a MRO8 module covers 3 slots.
Assignment of the Connection Modules
Front Rear
MCP module MST module
MAI module
MAT module (direct connection of sensors) MUT module (connection to the
MAT TS module or the MGT40 TS module for remote connection of sensors)
MGO module
MRO8 module (direct connection of relay outputs) only POS 9/Slot 14
MUT module (connection to the MRO 8 TS module or the MRO 16 TS module
via the MRC TS module for remote connection of relay outputs)
MUT module (connection to the MGT40 TS module for providing driver outputs
for the connection of magnetic valves, etc.)
MAO module
MAT module (direct connection of the 4–20 mA outputs)
MUT module (connection to the MAT TS module or the MGT40 TS module for
remote connection of the 4–20 mA outputs)
MBC module MBT module
Further information on the functions of the individual modules can be found in
Chapter 11 "Modules"
System Configuration/Maximum Loads
Maximum output current of an input 400 mA
Maximum output power of an input (Sensor and cable) 5 W
Maximum output power for a MAI module 40 W
Maximum output power for 8 MAI modules 320 W
Maximum input power for 8 MAI module 400 W
Maximum input power for a MIB module (for a track) 480 W
Maximum current load for a MIB module 20A
Maximum current load MIB module/GND terminal
(MAI module and MGO module current)
32A
Maximum output current for a MSP module (Rack - power pack) 6.5 A
Maximum output power for a MSP module (Rack - power pack) 150 W
