Figure 10 Wiring to a Late Model Dodge Ignition.
3,000-3,800
4,000-4,800
5,000-5,800
6,000-6,800
7,000-7,800
8,000-8,800
9,000-9,800
10,000-10,800
11,000-11,800
12,000-12,800
13,000-13,800
PN 8743
PN 8744
PN 8745
PN 8746
PN 8747
PN 8748
PN 8749
PN 8750
PN 8751
PN 8752
PN 8753
PN 87431
PN 87441
PN 87451
PN 87461
PN 87471
PN 87481
PN 87491
PN 87501
PN 87511
PN 87521
PN 87531
PN 8670
PN 8671
PN 8672
PN 8673
PN 8674
PN 8675
EVEN
INCREMENTS
3,100-3,900
4,100-4,900
5,100-5,900
6,100-6,900
7,100-7,900
8,100-8,900
9,100-9,900
10,100-10,900
11,100-11,900
12,100-12,900
13,100-13,900
ODD
INCREMENTS
RPM MODULE KITS
RPM MODULE
SELECTORS
3,000-5,200
4,600-6,800
6,000-8,200
7,600-9,800
9,000-11,200
10,600-12,800
Kits are supplied with five modules in 200 rpm increments.
RPM Selectors feature a dial that
allows you to choose between 12
different rpm limits in 200 rpm
