MSI 694 MASTER Manual

CHAPTER 2CHAPTER 2
CHAPTER 2CHAPTER 2
CHAPTER 2
HARDHARD
HARDHARD
HARD
WW
WW
W
ARE INSTARE INST
ARE INSTARE INST
ARE INST
ALLAALLA
ALLAALLA
ALLA
TIONTION
TIONTION
TION
2-21
Modem WModem W
Modem WModem W
Modem W
akak
akak
ak
e Up Connector: JMDM1e Up Connector: JMDM1
e Up Connector: JMDM1e Up Connector: JMDM1
e Up Connector: JMDM1
The JMDM1 connector is used for Modem add-on card that supports the
Modem Wake Up function.
Note: Modem wake-up signal is active low.
PIN SIGNAL
1NC
2GND
3 MDM_WAKEUP
4NC
5 5VSB
Note: To be able to use this function, you need a power supply that
provide enough power for this feature.
(Power supply with 750mA 5V Stand-by)
JMDM1
1
5
