Audio Port Connectors
Line Out is a connector for Speakers or Headphones. Line In is used
for external CD player, Tape player, or other audio devices. Mic is a connec-
tor for microphones.
1/8” Stereo Audio Connectors
Line Out Line In MIC
Joystick/Midi Connector
You can connect a joystick or game pad to this connector.
MSI Reminds You...
For advanced audio application, RealTek ALC650 audio chip
is provided to offer support for 6-channel audio operation and
can turn rear audio connectors from 2-channel to 4-/6-channel
audio. For more information on 6-channel audio operation,
please refer to Appendix. Using 4- or 6-Channel Audio Function.
