LED Status Indicators
APS LEDs
These APS (Active Phase Switching) LEDs indicate the current CPU power phase
mode. Follow the instructions
below to read.
: ON, : OFF
4 of the LEDs will light blue when CPU is in 4 phase power mode.
3 of the LEDs will light blue when CPU is in 3 phase power mode.
2 of the LEDs will light blue when CPU is in 2 phase power mode.
1 of the LEDs will light blue when CPU is in 1 phase power mode.
NB Phase LED
Lights blue when the NB is operating.
APS LEDs
NB Phase LED
