MSI 990FXA

2-2
Hardware Setup
MS-7640
Chapter 2
Hardware Setup
MS-7640
Chapter 2
SO CKE T AM3
JPWR2, p.2-9
Quck Components Gude
Back Panel,
p.2-10
CPU, p.2-4
CPUFAN, p.2-13
DDR3, p.2-7
SYSFAN1, p.2-13
JPWR1, p.2-9
SYSFAN2, p.2-13
SATA1~6, p.2-12
JUSB3, p.2-16
SYSFAN4, p.2-13
JTPM1, p.2-17
JFP1, JFP2, p.2-14
JBAT1, p.2-18
Debug LED Panel, p.2-23
JUSB1/2, p.2-15
POWER1, p.2-19
RESET1, p.2-19
TURBO1, p.2-19
JCOM1, p.2-17
J1394_1, p.2-16
JSP1, p.2-14
JAUD1, p.2-13
PCIE, p.2-20
PCIE, p.2-20
PCIE, p.2-20
PCI, p.2-20
SYSFAN3, p.2-13
JCI1, p.2-12
