MSI A68HM-E33 Series User Manual

English
22
JUSB1~2: USB 2.0 Expansion Connectors
This connector is designed for connecting high-speed USB peripherals such as USB
HDDs, digital cameras, MP3 players, printers, modems, and many others.
1
.
V
C
C
3
.
U
S
B
0
-
1
0
.
NC
5
.
U
S
B
0
+
7
.
G
r
o
u
n
d
9
.
N
o
P
i
n
8
.
G
r
o
u
n
d
6
.
U
S
B
1
+
4
.
U
S
B
1
-
2
.
V
C
C
Important
Note that the VCC and GND pins must be connected correctly to avoid possible
damage.
JTPM1: TPM Module Connector
This connector connects to a TPM (Trusted Platform Module). Please refer to the
TPM security platform manual for more details and usages.
10.No Pin
14.Ground
8.5V Power
12.Ground
6.Serial IRQ
4.3.3V Power
2.3V Standby power
1.LPC Clock
3.LPC Reset
5.LPC address & data p
in0
7.LPC address & data pin1
9.LPC address & data pin2
11.LPC address & data p
in3
13.LPC Frame

MSI A68HM-E33 Series Specifications

General

Form Factor	Micro ATX
Chipset	AMD A68H
Socket	FM2+
Memory Slots	2 x DIMM
Max Memory	32GB
PCI Slots	1
SATA Ports	4 x SATA 6Gb/s
USB 3.0 Ports	2
Memory Standard	DDR3
Audio	Realtek ALC887
LAN	Realtek RTL8111G
Video Outputs	VGA
USB 2.0 Ports	8 x USB 2.0 (4 rear, 4 via internal headers)
