MSI A68HM-E33 V2 Series User Manual

English
22
JUSB1~2: USB 2.0 Expansion Connectors
This connector is designed for connecting high-speed USB peripherals such as USB
HDDs, digital cameras, MP3 players, printers, modems, and many others.
1
.
V
C
C
3
.
U
S
B
0
-
1
0
.
NC
5
.
U
S
B
0
+
7
.
G
r
o
u
n
d
9
.
N
o
P
i
n
8
.
G
r
o
u
n
d
6
.
U
S
B
1
+
4
.
U
S
B
1
-
2
.
V
C
C
Important
Note that the VCC and GND pins must be connected correctly to avoid possible
damage.
JTPM1: TPM Module Connector
This connector connects to a TPM (Trusted Platform Module). Please refer to the
TPM security platform manual for more details and usages.
10.No Pin
14.Ground
8.5V Power
12.Ground
6.Serial IRQ
4.3.3V Power
2.3V Standby power
1.LPC Clock
3.LPC Reset
5.LPC address & data p
in0
7.LPC address & data pin1
9.LPC address & data pin2
11.LPC address & data p
in3
13.LPC Frame

MSI A68HM-E33 V2 Series Specifications

General

Chipset	AMD A68H
CPU Socket	FM2+
Memory Support	DDR3
Memory Slots	2
Max Memory	32GB
Form Factor	Micro ATX
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887
RAID Support	RAID 0, 1, 10
Memory Standard	DDR3 1600/1333 MHz
USB Ports	2 x USB 3.0
Audio Channels	7.1 Channel
LAN	Realtek RTL8111G
