MSI A68HM-E33 V2 Series User Manual

Русский
98








http://youtu.be/gkDYyR_83I4
13.+3.3
V
1.+3.3
V
14.-12V
2.+3.3V
15.Ground
3.Ground
16.PS-ON#
4.+5V
17.Ground
5.Ground
18.Ground
6.+5V
19.Ground
7.Ground
22.+5V
10.+12V
20.Res
8.PWR OK
23.+5V
11.+12V
21.+5V
9.5VSB
24.Ground
12.+3.3V
JPWR1
4.+12V
2
.Ground
3.+12V
1
.Ground
JPWR2







1
.
D
C
D
3
.
S
O
U
T
1
0
.
N
o
P
i
n
5
.
G
r
o
u
n
d
7
.
RT
S
9
.
R
I
8
.
C
T
S
6
.
D
S
R
4
.
D
T
R
2
.
S
I
N

MSI A68HM-E33 V2 Series Specifications

General

Chipset	AMD A68H
CPU Socket	FM2+
Memory Support	DDR3
Memory Slots	2
Max Memory	32GB
Form Factor	Micro ATX
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887
RAID Support	RAID 0, 1, 10
Memory Standard	DDR3 1600/1333 MHz
USB Ports	2 x USB 3.0
Audio Channels	7.1 Channel
LAN	Realtek RTL8111G
