MSI A88X-G45 GAMING - Expansion Slots and Graphics Cards

Chapter 1
1-17 Getting Started
Expansion Slots
This motherboard contains numerous slots for expansion cards, such as discrete
graphics or audio cards.
PCI_E1~6: PCIe Expansion Slots
The PCIe slot supports the PCIe interface expansion card.
PCIe x16 Slot
PCIe x16 Slot
PCIe 2.0 x1 Slot
PCI1: PCI Slot
The PCI slot supports additional LAN, SCSI, USB, and other add-on cards that comply
with PCI speci󰘰cations.
PCI Slot
Important
When adding or removing expansion cards, always turn o󰘯 the power supply and
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
