MSI A88XM-E35 V2 Series User Manual

頦錝侚剉
121
󳶰󱆃󱁝󲞷
󲍏󴹒󲋘󴽝󱂠󱂶A88XM-E35 V2/ A88XM-P33 V2/ A78M-E35 V2 󳼫󱑇 (MS-7721 v6.X)
Micro-ATX 󱁫󲦯󰆎A88XM-E35 V2/ A88XM-P33 V2/ A78M-E35 V2 󳼫󱑇󱁫󲦯󲡟󱨪󱂾
AMD A88X/ A78 󴓟󳑷󴃴󱁪󱅈󱕆󳼫󴄏󲉗󴌭󴈼󴷮󴷑󳢴󰆎󱁪󲝟󲔱 AMD FM2+/ FM2 󳼫󱑇󱬴󳘶
󱢘󲑰󴷮󴷑󳢴󰆎A88XM-E35 V2/ A88XM-P33 V2/ A78M-E35 V2 󳼫󱑇󲘀󱇋󱂶󵴈󲉗󴌭󰦉󱁃
󱁊󱕆󳢴󲩼󵦒󲂣󱘠󴰓󱏣󲟩󲩸󰆎
󲀳󱹰
BAT1
T:Line-In
M:Line- Out
B:MIC-Int
Top: LAN Jack
Bottom: USB3.0 ports
Top : mouse port
Bottom: keyboard port
JAUD1
JBAT1
JCI1
JUSB_PW1
JUSB_PW2
PCI_E1
PCI_E2
PCI1
JUSB2 JUSB1
JUSB3
JFP1
JFP2
SATA3 SATA6
SATA2
SATA5
SATA1 SATA4
SYSFAN1
SYSFAN2
CPUFAN
JPWR2
JPWR1
JTPM1
JCOM1
DIMM1
DIMM2
USB2.0 ports
USB2.0 ports
HDMI port
JLPT1
Top: VGA Port
Bottom: DV PortI-D

MSI A88XM-E35 V2 Series Specifications

General

Form Factor	Micro ATX
Chipset	AMD A88X
Socket	FM2+
Maximum Memory	32GB
PCIe x16 Slots	1
PCI Slots	1
Memory Standard	DDR3
PCIe x1 Slots	1
SATA Ports	6 x SATA 6Gb/s
USB 3.0 Ports	4
USB 2.0 Ports	8 (4 rear, 4 via header)
Video Outputs	HDMI, DVI, VGA
Audio	Realtek ALC887
LAN	Realtek RTL8111G
Memory Slots	2 x DIMM
