21
Back Panel Connectors
11 22 33 44
66 77 88 99
55
Item Description
1 PS/2 keyboard/ mouse port
2 2.5 Gbps LAN (RJ45) port
3 USB 2.0 Type-A ports (From B760 chipset)
4 Wi-Fi Antenna connectors
5 Audio jacks
6 USB 2.0 Type-A ports (From B760 chipset)
7 USB 3.2 Gen 2 10Gbps Type-A ports (From B760 chipset)
8 USB 3.2 Gen 2 10Gbps Type-C port (From B760 chipset)
9 Optical S/PDIF Out connector
