42
⚠
CAUTION
Do not connect the wrong type of LED strips. The JRGB connector and the JARGB_V2
connector provide different voltages, and connecting the ARGB 5V LED strip to the
JRGB connector will result in damage to the LED strip.
⚠
Important
∙
We strongly recommend that you install LED strips with the same specification to
achieve the best effects.
∙
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing the addressable RGB LED strip.
∙
Please use MSI’s software to control the extended LED strip.
EZ Debug LED
These LEDs indicate the debug status of the motherboard.
CPU - indicates CPU is not detected or fail.
DRAM - indicates DRAM is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates the booting device is not detected or fail.
