IO Panel
LED e󽙋ects:
Short press the LED switch button to change up to 26 modes.
Press and hold the LED switch for 3 seconds the LED flash white light once,
and then into the MSI motherboard Mystic Light synchronization mode. Short
press once to back to the Hub control mode.
Press and hold the LED switch for 6 seconds to turn o󽙋 the LED.
1. Power button
2. Reset button
3. Power LED
4. USB 3.2 Gen2 Type C
5. USB 3.2 Gen1 Type A
6. Mic in
7. Audio out
8. LED switch button
(For GUNGNIR 110R, 111R)
2
3 4 5 6 7 81
