MSI B150M BAZOOKA User Manual

3
Speci󰄈cations
Specifications
CPU
Supports 6th Gen Intel
®
Core
™
i3/i5/i7 processors, and Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset
Intel
®
H170 Chipset (H170M BAZOOKA)
Intel
®
B150 Chipset (B150M BAZOOKA)
Memory
● 4x DDR4 memory slots, support up to 64GB
▶ Supports DDR4 2133 MHz
● Dual channel memory architecture
● Supports ECC, un-buffered memory
● Supports Intel
®
Extreme Memory Profile (XMP)
Expansion Slots
● 1x PCIe 3.0 x16 slot
● 2x PCIe 3.0 x1 slots
Onboard Graphics
● 1x HDMI
™
port, support a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
● 1x DVI-D port, support a maximum resolution of
1920x1200@60Hz
Storage
Intel
®
H170/ B150 Chipset
● 6x SATA 6Gb/s ports
● 1x SATAe port (PCIe 3.0 x2)*
● Supports RAID 0, RAID1, RAID 5 and RAID 10 (only for
H170M BAZOOKA)
● Supports Intel
®
Smart Response Technology for Intel
Core
™
processors. (only for H170M BAZOOKA)
* SATAe port is backward compatible with SATA.
USB
● Intel
®
H170/ B150 Chipset
▶ 6x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on
the back panel, 2 ports available through the internal
USB connector)
▶ 6x USB 2.0 (High-speed USB) ports (2 ports on the
back panel, 4 ports available through the internal USB
connectors)
Audio
● Realtek
®
ALC887 Codec
● 7.1-Channel High Definition Audio
LAN 1x Realtek RTL8111H Gigabit LAN controller
Continued on next page

MSI B150M BAZOOKA Specifications

General

Form Factor	Micro ATX
Chipset	Intel B150
Socket	LGA 1151
Memory Slots	4
Maximum Memory	64 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.1 Gen 1, 6 x USB 2.0
Audio	Realtek ALC887
RAID Support	RAID 0, 1, 5, 10
Memory Speed	2133 MHz
Video Outputs	HDMI, DVI-D
LAN	Realtek RTL8111H
