Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1,SYS_FAN1~5, PUMP_FAN1 Fan Connectors 33
CPU_PWR1, ATX_PWR1, PCIE_PWR1 Power Connectors 30
CPU Socket LGA1151 CPU Socket 25
DIMMA1/ A2/ B1/ B2 DIMM Slots 26
JAUD1 Front Audio Connector 34
JBAT1 Clear CMOS (Reset BIOS) Jumper 37
JCI1 Chassis Intrusion Connector 34
JCOM1 Serial Port Connector 36
JFP1, JFP2 Front Panel Connectors 31
JLPT1 Parallel Port Connector 36
JTBT1
Thunderbolt Add-on Card
Connector
35
JTPM1 TPM Module Connector 35
JUSB1~2 USB 2.0 Connectors 32
JUSB4 USB 3.1 Gen1 Connector 31
M2_1 M.2 Slot (Key M) 28
PCI_E1~6 PCIe Expansion Slots 27
SATA1~5 SATA 6Gb/s Connectors 29
