MSI B85-G43 Series User Manual

Chapter 1
1-5 Getting Started
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
6x USB 2.0 ports
1x HDMI port
1x VGA port
1x DVI-D port
1x LAN (RJ45) port
2x USB 3.0 ports
6x audio jacks
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
Internal
Connectors
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
6x SATA 6Gb/s connectors
For Z87-G43/ H87-G43.
4x SATA 6Gb/s connectors and 2x SATA 3Gb/s connectors
For B85-G43.
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.0 connectors (supports additional 2 USB 3.0 ports)
2x 4-pin CPU fan connectors
3x 4-pin system fan connectors
1x Clear CMOS jumper
1x Front panel audio connector
2x System panel connectors
1x TPM module connector
1x Serial port connector
1x Parallel port connector
1x Chassis Intrusion connector
󰀲
󰀲
󰀲
-
󰀲
-
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
I/O
Controller
NUVOTON NCT6779 Controller Chip󰀲
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
󰀲
󰀲
󰀲
BIOS
Features
64 Mb 󰘱ash (Z87-G43)
128 Mb 󰘱ash (H87-G43/ B85-G43)
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
Multi-language
󰀲
󰀲
󰀲
󰀲
󰀲
Special
Features
DigitALL Power
Military Class 4
OC Genie 4
CLICK BIOS 4
All Solid CAPs
AMD CrossFire
PCI Express Gen 3
Sound Blaster Cinema (optional)
Super RAID
USB 3.0
SATA 6Gb/s
HDMI
Command Center
Live Update
M-Flash
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲

MSI B85-G43 Series Specifications

General

Chipset	Intel B85
Socket	LGA 1150
Memory Support	DDR3
Max Memory	32GB
Memory Standard	DDR3 1066/1333/1600 MHz
Form Factor	ATX
PCIe x1 Slots	2
PCI Slots	3
SATA 6Gb/s	4
SATA 3Gb/s	2
Audio	Realtek ALC892
Memory Slots	4
USB 3.0 Ports	4
USB 2.0 Ports	8
Ethernet	Realtek 8111G
RAID Support	RAID 0, RAID 1, RAID 5, and RAID 10
Onboard Video	Supported only by CPU with integrated graphics
