Overview
1-91-8
1
Power Button
Press the power button to turn the system on and o.
2
Hard Disk Drive LED
This indicator shows the activity status of the HDD. It ashes when the
system is accessing data on the HDD and remains o when no disk
activity is detected�
3
USB 3.1 Gen 1 Port (Type-C)
USB 3�1 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed
data transfer for various devices, such as storage devices, hard drives,
video cameras, etc�
The slim and sleek USB Type-C connector features reversible plug
orientation and up to 5V/3A power supply for external devices�
4
USB 3.1 Gen 1 Port
USB 3�1 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed
data transfer for various devices, such as storage devices, hard drives,
video cameras, etc�
5
Headphone Jack
This connector is provided for headphones or speakers�
6
Microphone Jack
This connector is provided for microphones�
7
HDMI-Out Port (Optional)
The High-Denition Multimedia Interface (HDMI) is an all-digital audio/
video interface capable of transmitting uncompressed streams� HDMI
supports all TV format, including standard, enhanced, or high-denition
video, plus multi-channel digital audio on a single cable�
8
PS/2
®
Keyboard / Mouse Port
The PS/2
®
keyboard / Mouse DIN connector for PS/2
®
keyboard / Mouse�
9
USB 2.0 Port
The USB (Universal Serial Bus) port is for attaching USB devices such
as keyboard, mouse, or other USB-compatible devices� It supports up to
480Mbit/s (Hi-Speed) data transfer rate�
10
VGA Port (Optional)
The VGA port supports monitors and other VGA interface devices�
