2-14
Introductions
Right Side View
1. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported. Connect your
speakers to the proper connectors as shown below.
Headphone out: Used for speakers or headphones.
Mic In/Line In: Used for an external microphone.
2. USB Port
The USB port allows you to connect USB-interface peripheral devices, such as the mouse,
keyboard, modem, portable hard disk module, printer and more.
1. Audio Port Connectors
2. USB Port
3. Optical Drive Device
4. Power Button
5. Kensington Lock Hole
4
3
1
2
5
