2-19
Introductions
Bottom Side View
1. Battery Lock/ Unlock Button
Battery cannot be moved when the button is positioned on lock status. Once the button is slid to
unlock position, the battery is removable.
2. Battery Pack
This notebook will be powered by the battery pack when the AC adapter is disconnected.
1. Battery Lock/ Unlock Button
2. Battery Pack
3. Battery Release Button
4. Ventilator
1
2
4
3
To Next Page
