Specifications
Continued from previous page
Internal Connectors
∙ 1x 24-pin ATX main power connector
∙ 3x 8-pin ATX 12V power connectors
∙ 1x flat 4-pin ATX 12V power connector (Provides additional
power for PCIe x16 slots)
∙ 8x SATA 6Gb/s connectors
∙ 1x U.2 port
∙ 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
∙ 2x USB 3.2 Gen 1 connectors (support additional 4 USB 3.2
Gen 1 ports)
∙ 1x USB 3.2 Gen 2 Type-C Port
∙ 1x 4-pin CPU fan connector
∙ 4x 4-pin system fan connectors
∙ 2x 4-pin extend system fan connectors
∙ 1x 4-pin water-pump fan connector
∙ 1x 3-pin Water Flow connector
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x TPM module connector
∙ 1x Chassis Intrusion connector
∙ 1x 2-pin Thermal Sensors connector
∙ 1x Thunderbolt Add-on Card Connector
∙ 1x Virtual RAID on CPU connector
LED Connectors
∙ 1x 4-pin RGB LED connector
∙ 2x 3-pin RAINBOW LED connectors
∙ 1x 3-pin CORSAIR connector
Switch ∙ 1x Multi-BIOS switch
Internal Buttons
∙ 1x Power button
∙ 1x Reset button
∙ 1x OC GENIE 4 knob
Jumpers
∙ 1x Clear CMOS jumper
∙ 1x Slow mode booting jumper
Debug LED
∙ 1x Debug Code LED
∙ 4x EZ Debug LEDs
