Introductions
2-8 2-9
Left Side View
1. Kensington Lock
This notebook provides a Kensington lock hole, which allows users to secure the
notebook in place.
2. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
3. USB 3.1 Gen 1/ Gen 2 Port (optional)
USB 3.1 Gen 1/ Gen 2, the SuperSpeed USB/ SuperSpeed USB 10Gbps, delivers
the higher interface speeds for connecting various devices, such as storage devices,
hard drives, or video cameras, and offers more advantages over high-speed data
transferring.
4. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported.
Microphone
• Used for an external microphone.
Headphone out/ S/PDIF-out
• A connector for speakers or headphones.
• Connect the Front speakers here.
• The S/PDIF connector is also provided for digital audio
transmission to external speakers through an optical fiber
cable.
