User's Manual
2-6 2-7
Right Side View
1. Power Button
Power
Power Button
• Use this button to turn the notebook power ON and OFF.
• Use this button to awake the notebook from the sleep state.
2. USB 2.0 Port
The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the
mouse, keyboard, modem, portable hard disk module, printer, etc.
3. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
4. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
5. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
6. Thunderbolt (Type-C) (optional)
Thunderbolt™ 3 supports up to 40Gbps data rate, dual 4K displays monitor output,
USB 3.1 connection, and portable charging power up to 5V/3A when AC power is
connected.
