MSI GX70 - Connector and Cable Removal; General Screw Removal for Case

GX70（MS-176K）Disassembly Guide
■ 6、SEPARATE UPPER CASE AND LOWER CASE
■
6.10：Firstly push connector according to the
direction as pic shows; then remove the cable.
Compon nt
P/N
Qty
Keyboard
S1N-3EUS2Y1-SA0
1
6.12：Remove 12 screws (M2.5*7mm).
Attention: the screw driver torque is 1.8-2.2Kgf-cm
Component
P/N
Qty
Screw
E43-1257002-G68
11
