GX70（MS-176K）Disassembly Guide
■ 8、UPPER CASE ASSY
8.1：Remove 2 screws (M2*3mm), then remove the
T/P board.
Attention: the screw driver torque is 1.2-1.6Kgf-cm
Component
P/N
Qty
screw
E43-1203003-H29
2
Touchpad board
607-176KC-01S
1
Upper Case
307-762C217-Y31
1
8.2：：Remove the T/P iron shielding.
8.3： Remove the T/P module.
Component
P/N
Qty
Touchpad Module
S78-3700630-E47
1
