MSI GX70 - LCD Module Assembly Steps; LCD Cover Rubber Removal; LCD Bezel Removal

GX70（MS-176K）Disassembly Guide
■ 9、 LCD MODULE ASSY
9.1：Remove the 2 cover rubber.
Component
P/N
Qty
Rubber
E2Y-6320931-Y40
4
9.2 Remove the 2 screws (M2.5*5mm), then remove
the LCD bezel, should begin from the two sides, then
the upside to downside.
Attention: the screw driver torque is 1.8-2.2Kgf-cm
Component
P/N
Qty
Screw
E43-1255002-G68
2
LCD Bezel
307-763B218-U22
1
