MSI GX70 - Main Board Removal; Speaker and Woofer Module Removal

GX70（MS-176K）Disassembly Guide
■ 7、LOWER CASE ASSY
7.6：Remove the 1 screw (M2.5*5mm).then remove
the main board from Lower case.
Attention: the screw driver torque is 1.8-2.2Kgf-cm
Component
P/N
Qty
Screw
E43-1255002-G68
1
Main Board
607-176K1-01S
1
7.7：Remove the Speaker and woofer module from
lower case.
Component
P/N
Qty
Woofer
S33-S030111-F33
1
Speaker Module
S33-A020230-F33
1
Lower Case
307-761D232-Y31
1
