GX70（MS-176K）Disassembly Guide
■ 9、 LCD MODULE ASSY
9.9:Remove the CMOS camera module according
to the sequence as pic shows.
Component
P/N
Qty
Camera Module
S1F-0005300-B36
1
9.10:Remove the MIC Module as left picture show.
Component
P/N
Qty
MIC Module
S34-2101260-N44
1
