MSI H55M-E21 - Mainboard Specifications

1-2
Gettng Started
Manboard Spec󰘰catons
Processor Support
Intel
®
Core™ 7, Core™ 5 (Lynn󰘰eld & Clarkdale), Core™ 3 and Pentum
®
processor
n the LGA1156 package
(For the latest nformaton about CPU, please vst http://www.ms.com/ndex.
php?func=cpuform2)
Base Clock
133 MHz
Chpset
Intel
®
H55 chpset
Memory Support
2 DDR3 DIMMs support DDR3 2133*(OC)/ 2000*(OC) /1600*(OC)/ 1333/ 1066
DRAM (8GB Max)
Supports Dual-Channel mode
*(For more nformaton on compatble components, please vst
http://www.ms.com/ndex.php?func=testreport)
LAN
Supports LAN 10/100/1000 by Realtek
®
RTL8111E (for H55M-E32 & H55M-E23)
Supports LAN 10/100 by Realtek
®
RTL8105E (for H55M-E21)
Audo
Chp ntegrated by Realtek
®
ALC892 (for H55M-E32)/ ALC887 (for H55M-E21 &
H55M-E23)
Flexble 8-channel audo wth jack sensng
Complant wth Azala 1.0 Spec
SATA
6 SATA 3Gb/s (SATA1~6) ports by Intel
®
H55
Connectors
Back panel
1 PS/2 keyboard port
1 PS/2 mouse port
6 USB 2.0 ports (for H55M-E32)/ 4 USB 2.0 ports (for H55M-E21 & H55M-E23)
1 HDMI port**
1 VGA port**
1 DVI-D port**
1 LAN port
6 󰘱exble audo ports (for H55M-E32)
3 󰘱exble audo ports (for H55M-E21 & H55M-E23)
**(The VGA, DVI-D & HDMI ports only work wth Integrated Graphcs Processor)
■
■
■
■
■
■
■
■
■
■
■
■
-
-
-
-
-
-
-
-
-
