Page #143 background imageLoading...
Page #143 background image
43
繁體中文
內建接頭  個 24-pin ATX 主電源接頭
 個 4-pin ATX 2V 電源接頭
2 個 SATA 6Gb/s 接頭
2 個 SATA 3Gb/s 接頭
2 個 USB 2.0 接頭 (可另延伸 4 個 USB 2.0 連接埠)
 個 USB 3.0 接頭 (可另延伸 2 個 USB 3.0 連接埠)
 個 4-pin CPU 風扇接頭
 個 4-pin 系統風扇接頭
 個 3-pin 系統風扇接頭
 個前置音效接頭
2 個系統面板接頭
 個機殼開啟警告接頭
 個 TPM 模組接頭
 個序列連接器接頭
 個清除 CMOS 跳線
2 個 USB 電源跳線
BIOS 功能 UEFI AMI BIOS
ACPI 5.0, PnP .0a, SM BIOS 2.7, DMI 2.0
支援多國語
尺寸 Micro-ATX
8.9 in. x 6.8 英吋 (22.6 x 7.3 公分)
如需了解 CPU 的詳細訊息,請造訪微星科技網站
http://www.msi.com/service/cpu-support/
如需了解相容元件的詳細訊息,請造訪微星科技網站
visit http://www.msi.com/service/test-report/
