17
Continued from previous column
M.2 SSD Slots
3x M.2 slots (Key M)
M2_1 & M2_2 slot (From CPU)
Supports up to PCIe 4.0 x4
M2_1 supports 2280/ 22110 storage devices
M2_2 supports 2260/ 2280 storage devices
M2_3 slot (From B650 chipset)
Supports up to PCIe 4.0 x4*
Supports 2260/ 2280 storage devices
* M2_3 & PCI_E2 share the bandwidth. M2_3 will run at x2 speed and PCI_E2
will run at x2 speed when installing devices in both slots.
RAID
Supports RAID 0, RAID 1 and RAID 10 for SATA storage
devices*
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe
storage devices
* SATA_A1 & SATA_A2 do not support RAID function.
Audio
Realtek® ALC4080 Codec
7.1-Channel USB High Performance Audio
Supports up to 32-bit/384kHz playback on front panel
Supports S/PDIF output
LAN
1x Realtek 8125BG 2.5Gbps LAN controller
Wireless LAN &
Bluetooth®
AMD® Wi-Fi 6E RZ616
The Wireless module is pre-installed in the M.2 (Key-E)
slot
Supports MU-MIMO TX/RX
Supports 20MHz, 40MHz, 80Mhz, 160Mhz bandwidth in
2.4GHz/ 5GHz or 6GHz bands*
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.2**
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in
Windows 10 21H1 and Windows 11.
** Bluetooth 5.2 will be ready in Windows 10 21H1 and Windows 11.
Power Connectors
1x 24-pin ATX main power connector
2x 8-pin EPS 12V power connectors
Continued on next column
