MSI MAG B650 TOMAHAWK WIFI User Manual

18
Continued from previous column
Internal USB
Connectors
AMD® B650 Chipset
 1x USB 3.2 Gen 2 10Gbps Type-C connector
 1x USB 3.2 Gen 1 5Gbps connector
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
 2x USB 2.0 connectors
• Supports additional 4 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 1x 4-pin water-pump fan connector
 6x 4-pin System fan connectors
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x TPM module connector
 1x Tuning Controller connector
Jumpers  1x Clear CMOS jumper
LED Features
 2x 4-pin RGB LED connector
 2x 3-pin ARGB_V2 LED connectors
 4x EZ Debug LED
Back Panel
Connectors
 1x Flash BIOS button
 1x DisplayPort
 1x HDMI™ port
 3x USB 3.2 Gen 2 10Gbps Type-A ports (From CPU)
 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From B650
chipset)
 4x USB 3.2 Gen 1 5Gbps Type-A ports (From B650
chipset)
 2x USB 2.0 Type-A ports (From B650 chipset)
 1x LAN (RJ45) jack
 2x Wi-Fi Antenna connectors
 5x audio jacks
 1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687D-R Controller Chip
Continued on next column

MSI MAG B650 TOMAHAWK WIFI Specifications

General

Processor socket	Socket AM5
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 7 7th Gen, AMD Ryzen 9 7th Gen
ECC	No
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	4800, 5000, 5200, 5400, 5600, 5800, 6000, 6200, 6400, 6600 MHz
RAID levels	0, 1, 10
RAID support	Yes
Supported storage drive interfaces	M.2, SATA
Parallel processing technology support	-
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
LAN controller	Realtek RTL8125B
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC4080
Component for	PC
Product color	Black
Motherboard chipset	AMD B650
PC health monitoring	Fan
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 11 x64

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
