15
Specifications
Specifications
CPU
∙ Supports 12th Gen Intel® Core™ Processors, Pentium®
Gold and Celeron® Processors
∙ Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B660 Chipset
Memory
∙ 4x DDR4 memory slots, supporting up to 128GB*
∙ Supports 1R 2133/2666/3200 MHz (by JEDEC & POR)
∙ Max overclocking frequency:
▪ 1DPC 1R Max speed up to 4800+ MHz
▪ 1DPC 2R Max speed up to 4000+ MHz
▪ 2DPC 1R Max speed up to 4000+ MHz
▪ 2DPC 2R Max speed up to 3600+ MHz
∙ Supports Dual-Channel mode
∙ Supports non-ECC, un-buffered memory
∙ Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slot
∙ 2x PCIe x16 slots
▪ PCI_E1 (From CPU)
▫ Support up to PCIe 4.0
▪ PCI_E2 (From B660 chipset)
▫ Support up to PCIe 3.0 x4
∙ 1x PCIe 3.0 x1 slot (From B660 chipset)
Multi-GPU ∙ Supports AMD CrossFire™ Technology
Onboard Graphics
∙ 1x HDMI 2.1 with HDR port, supporting a maximum
resolution of 4K 60Hz*/**
∙ 1x DisplayPort 1.4 port with HBR3, supporting a maximum
resolution of 4K 60Hz*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
Continued on next column
