MSI MAG B660 TOMAHAWK WIFI DDR4

34
Overview of Components
6. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
30º30º
3. If there is no EZ M.2 clip installed, please install the supplied EZ M.2 clip kit in the
M.2 slot according to your SSD length.
4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle.
5. Rotate the EZ M.2 clip to fix the M.2 SSD.
5
4
3
