MSI MAG B660M MORTAR MAX WIFI DDR4 - Jdash1: 調試控制器接頭; JTBT1: Thunderbolt 擴充卡接頭

33
󳻱󱯳󱽷󳲞󹲋
󴨡󳲞󹲋󵭡󴁘󸹒󳲞󳻱󱯳󱽷󾖜
1
2 16
15
󳲞󷉥 󸏁󷵏󲂁󶏺 󳲞󷉥 󸏁󷵏󲂁󶏺
1 TBT_FORCE_PWR 2 TBT_S0IX_ENTRY_REQ
3
TBT_CIO_PLUG_
EVENT#
4 TBT_S0IX_ENTRY_ACK
5 SLP_S3#_TBT 6
TBT_PSON_OVERRIDE_N
7 SLP_S5#_TBT 8 No Pin
9 Ground 10 SMBCLK_VSB
11 DG_PEWAKE# 12 SMBDATA_VSB
13 TBT_RTD3_PWR_EN 14 Ground
15 TBT_CARD_DET_R# 16 PD_IRQ#
󸔩󸑵󳲢󱵺󲑠󳲞󹲋
󴨡󳲞󹲋󲁗󸹒󳲞󸼫󳺙󳚱󹂦󶹌󵷜󸔩󸑵󳲢󱵺󲑠󴟜󶩭󾖜
󳲞󷉥 󸏁󷵏󲂁󶏺 󳲞󷉥 󸏁󷵏󲂁󶏺
1 No Pin 2 NC
3
MCU_SMB_SCL_M 4 MCU_SMB_SDA_M
5 VCC5 6 Ground
1
2
5
6
