Overview of Components
M.2 slots with examples of various combination possibilities
1xM.2 PCIe SSD + 6xSATA HDDs
2xM.2 PCIe SSDs + 4xSATA HDDs
1xM.2 PCIe SSD + 1xM.2 SATA SSD +
4xSATA HDDs
SATA4SATA4SATA4 SATA4SATA4
SATA2SATA2SATA2 SATA1SATA1SATA1
SATA1
SATA1
SATA3SATA3SATA3 SATA3SATA3
M.2 PCIe
M.2 PCIe
M.2 PCIe
M.2 SATA
M.2 PCIe
M.2 SATA
M.2 SATA
1xM.2 SATA SSD + 5xSATA HDDs
M.2 SATA
2xM.2 SATA SSDs + 3xSATA HDDs
SATA6 SATA6 SATA5 SATA5
