MSI MAG Z390 TOMAHAWK - Onboard LEDs; EZ Debug LED; DIMM LEDs

38
Onboard LEDs
Onboard LEDs
EZ Debug LED
These LEDs indicate the debug status of the motherboard.
CPU - indicates CPU is not detected or fail.
DRAM - indicates DRAM is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates the booting device is not detected
or fail.
DIMM LEDs
DIMM LEDs
These LED indicate the memory modules are installed.
