18
Continued from previous column
Back Panel
Connectors
1x DisplayPort
1x HDMI™ port
1x Clear CMOS button
1x Flash BIOS button
4x USB 3.2 Gen 1 5Gbps Type-A ports (From Hub GL3523)
4x USB 3.2 Gen 2 10Gbps Type-A ports (From Z790
chipset)
1x USB 3.2 Gen 2 10Gbps Type-C port (From Z790 chipset)
1x USB 3.2 Gen 2x2 20Gbps Type-C port (From Z790
chipset)
1x 2.5Gbps LAN (RJ45) jack
2x Wi-Fi antenna connectors
5x Audio jacks
1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687D-M Controller Chip
Hardware Monitor
CPU/ System/ Chipset temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Form Factor
ATX Form Factor
9.6 in. x 12 in. (244 mm x 305 mm)
BIOS Features
1x 256 Mb flash
UEFI AMI BIOS
ACPI 6.4, SMBIOS 3.5
Multi-language
Continued on next column
