Screw List
Please refer to the screw list below while proceeding the disassembly and assembly
of the computer.
Note: This screw list is for reference only and may vary from models to models. It
is highly recommended that users contact the authorized service center for further
assistance.
Component Screw Type Quantity
Lift Stand (Modern AM242P 1MG/ AM242TP 1MG) M4*13.5 4
Fixed Stand (Modern AM242 1MG) M3*5 2
Rear Cover M3*4 4
M3*15 1
Panel Rear Cover M3*4 4
Stand Bracket M3*5 4
B3*7 3
Mainboard Shield M3*5 6
#4-40 2
Speakers B2.5*5.2 4
FAN M2.5*4 2
Thermal Module M2.5*4 4
SSD M2*3 1
Wireless Card M2*3 1
Mainboard M3*5 3
DC-In Cable B3*7 2
SATA Cable M3*3.5+4.8 2
Converter Board B3*7 2
Navi Board B3*7 2
Deco Strip B2.5*5.4 4
LCD Bezel M3*3 11
Middle Bracket M3*5 3
