MSI MPG X670E CARBON WIFI User Manual

23
Item Description
9
Smart button - We provide 4 functions for the smart button to achieve.
Please refer to the BIOS manual for details about selecting the smart
button function.
∙ Reset (default) - press the smart button to reset the system.
∙ Mystic Light on/ off - press the smart button to turn on/ off all the
onboard LEDs. The Mystic Light on/ off function mode is unavailable
when the LED_SW1 (EZ LED Control) switch turns OFF.
∙ Safe Boot - press and hold the smart button and start the system
simultaneously to boot in Safe Boot mode. The system will boot with
default and lower the PCIe (from CPU) mode.
∙ Turbo Fan - press the smart button for all fans to operate full speed or
default speeds.
10
HDMI™ port
11
USB 3.2 Gen 2 10Gbps Type-C port (From CPU)
∙ DisplayPort Alt Mode
12 USB 3.2 Gen 2 10Gbps Type-A ports (From CPU)
13 USB 3.2 Gen 2x2 20Gbps Type-C port (From X670 chipset)
14 Optical S/PDIF Out connector

MSI MPG X670E CARBON WIFI Specifications

General

Processor socket	Socket AM5
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen™ 7
Maximum number of SMP processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA II
Parallel processing technology support	-
Number of SATA III connectors	6
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
LAN controller	Realtek RTL8125-BG
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC4080
Component for	PC
Motherboard chipset	AMD X670
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 Home x64, Windows 11 x64
Cables included	SATA

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
