MSI MPG Z790 EDGE WIFI DDR4 User Manual

18
Continued from previous column
LED Features
 1x 4-pin RGB LED connector
 3x 3-pin ARGB Gen2 LED connectors
 4x EZ Debug LED
 1x LED Demo connector
Back Panel
Connectors
 1x DisplayPort
 1x HDMI™ port
 1x Clear CMOS button
 1x Flash BIOS button
 4x USB 3.2 Gen 1 5Gbps Type-A ports (From Hub GL3523)
 4x USB 3.2 Gen 2 10Gbps Type-A ports (From Z790
chipset)
 1x USB 3.2 Gen 2 10Gbps Type-C port (From Z790 chipset)
 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From Z790
chipset)
 1x 2.5Gbps LAN (RJ45) jack
 2x Wi-Fi antenna connectors
 5x Audio jacks
 1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687D-M Controller Chip
Hardware Monitor
 CPU/ System/ Chipset temperature detection
 CPU/ System/ Pump fan speed detection
 CPU/ System/ Pump fan speed control
Form Factor
 ATX Form Factor
 9.6 in. x 12 in. (244 mm x 305 mm)
BIOS Features
 1x 256 Mb flash
 UEFI AMI BIOS
 ACPI 6.4, SMBIOS 3.5
 Multi-language
Continued on next column

MSI MPG Z790 EDGE WIFI DDR4 Specifications

General

Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Gold
Supported processor sockets	LGA 1700
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3466, 3600, 3733, 3866, 4000, 4266, 4400, 4533, 4600, 4800, 5000, 5066, 5200, 5333 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
DisplayPort version	1.4
USB 2.0 ports quantity	0
RAID levels	0, 5, 10
Internal storage capacity	10 GB
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express
Cables included	SATA
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Component for	PC
Motherboard chipset	Intel Z690
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Parallel processing technology support	Not supported

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
